The DepthTrax Edge™ features a full-color display and delivers precise depth readings along with real-time water temperature. With built-in Bluetooth®, it seamlessly connects to the DepthTrax® PLUS app, unlocking expanded sonar views, advanced features, and enhanced control directly from your smartphone.

Designed for versatility, it is compatible with any 200 kHz transducer equipped with temperature sensing.

For complete specifications and detailed product information, please visit the DepthTrax Edge Product Page.

COMPATIBILITY
WHAT'S INCLUDED
INSTRUCTIONS
VIDEOS
SPECIFICATIONS
$129.99
$129.99
Shipping calculated at checkout.

COMPATIBILITY

DepthTrax 2BX (DT2BX)

DepthTrax 1BX (DT1BX)

D10DX

DF1000DT

1000-01T

Any 200 kHz Transducer with Temperature

NOTE: To be compatible, the transducer must have a MALE HawkEye® 4-Pin Connector.

WHAT'S INCLUDED

DepthTrax® Edge Display Assembly

  • Integrated 4-Pin Plug-&-Play Connector

Chrome Bezel & Silver Face Plate

White Bezel & Face Plate

Black Bezel & Face Plate

In-Dash Mounting Bracket

INSTRUCTIONS

HawkEye® Installation and Operation Manuals

VIDEOS

HawkEye® TechTutorial™ | DepthTrax® Boat
Mount Depth Finders | Installation & Operation

HawkEye® TechTutorial™ | Boat Mount Depth
Finders | Installation & Operation (Full Video)

HawkEye® TechTutorial™ | Installing a Boat
Mount Depth Finder Display

HawkEye® TechTutorial™ | Transom Mounting a
Transducer on a Boat

HawkEye® TechTutorial™ | Gluing a
Transducer Inside the Hull of a Boat

HawkEye® TechTutorial™ | Installing a
Thru-Hull Transducer

HawkEye® Product
SnapShot™ | DepthTrax® Boat Mount Depth Finders

SPECIFICATIONS

DIMENSIONS:

2" Diameter x 1.75" Depth (51 x 45 mm)

SCREEN SIZE:

Height: 1.65" Width: .87" (42 x 22 mm)

OPERATING TEMPERATURE:

0~160°F (-18~71 °c)

DEPTH RANGE:

2.5 ft (.7 m) ~ 600 ft (180 m)

WATERPROOF RATING:

IPX5 (front face only)

TRANSDUCER CONNECTOR:

4-Pin, Water Resistant

POWER REQUIREMENT:

12-14 VDC

CURRENT DRAW:

200 mAh
